Reverse Proxy

  • Fabian Sinner
  • November 29, 2023

Table of content

    Reverse Proxy

    A reverse proxy is a type of proxy server that acts as an intermediary between external requests from the Internet and the servers running on an internal network. This is in contrast to a conventional (forward) proxy, which acts on behalf of client users, instead working on behalf of one or more servers.

    What is a proxy server?

    A proxy server is an intermediary between a user and the Internet; it sends requests to websites, services, and resources on behalf of the user. It provides anonymity, enhanced security, access control, and can filter or optimize network traffic. Proxies can also bypass regional restrictions.

    What is a reverse proxy used for?

    A reverse proxy receives requests from external users and forwards them to internal servers. The actual servers remain invisible to the external user. It can distribute the load across several internal servers to improve the efficiency and reliability of server operation. This process is known as load balancing.

    Placing a reverse proxy between the Internet and the internal servers can serve as an additional layer of security because it can filter malicious requests before they reach the internal servers. It can also be responsible for SSL encryption, which means that it manages SSL certificates and performs the encryption and decryption of data. This reduces the load on the internal servers.

    A reverse proxy can cache frequently requested content to also reduce the load on internal servers and respond more quickly to requests. It can also compress the data to reduce bandwidth usage and improve load times. Some reverse proxies offer web application firewall functions that protect the servers behind them from attacks.

    Overall, the technology improves the security, performance and scalability of web applications and services. It is particularly important for large, complex websites and web applications that require high security and optimal performance.

    What are the advantages of a reverse proxy?

    Using a reverse proxy can have several advantages. For example, it offers an additional layer of security. By filtering and processing requests before they reach internal servers, it protects against attacks and unwanted data traffic. The anonymization of the backend servers also increases security, as the servers’ actual IP addresses remain hidden.

    Reverse proxies can also distribute incoming data traffic across several servers. This load balancing optimizes the use of resources, avoids overloading individual servers, and improves the system’s overall performance and reliability.

    By adding or removing servers behind the reverse proxy, the infrastructure can be easily scaled without these changes being visible to the end user. This facilitates the expansion of server capacity to handle increased traffic.

    A reverse proxy enables centralized certificate management by taking over the encryption and decryption of SSL/TLS connections. The ability to cache frequently requested content can reduce the load on backend servers and speed up response times for users.

    Compressing incoming and outgoing data can reduce bandwidth usage and improve data transfer speeds. In the event of a server failure, reverse proxies can redirect traffic to other running servers, minimizing downtime and ensuring continuous availability.

    Some reverse proxies offer WAF functionalities that protect web applications from specific attacks such as cross-site scripting (XSS) or SQL injection. Reverse proxies can also intelligently control traffic based on specific criteria (such as URL, HTTP header, etc.), allowing finer control over the distribution of traffic. By bundling traffic and management functions into one central point, a reverse proxy simplifies network management.

    These advantages make reverse proxies a frequently used component in modern network architectures, especially in environments that require high performance, security, and scalability.

    What are the disadvantages of a reverse proxy?

    Although reverse proxies offer many advantages, there are also some disadvantages and challenges that should be considered. For example, a reverse proxy can become a single point of failure if it is not configured properly. If the proxy fails, it can affect all access to the servers behind it.

    With insufficient resources or poor configuration, the reverse proxy can also become a performance bottleneck, negatively impacting response times for end users.

    Implementing and managing a reverse proxy can incur additional costs. The introduction of a reverse proxy into the infrastructure also increases the complexity of the network. This requires more expertise for setup, maintenance, and troubleshooting.

    Although the implementation improves security, it can itself become the target of attacks. If it is compromised, attackers can gain access to the entire network. Furthermore, when using caching functions, inconsistencies can occur if the cache is not properly synchronized or updated.

    For the servers behind a reverse proxy, the actual IP addresses of the end users are often not visible, as they only see the IP address of the proxy. This can make logging and analysis more difficult. When using SSL/TLS termination on the reverse proxy, security aspects such as the secure storage of keys and certificates must be taken into account. Like any other network component, the implementation requires regular updates and maintenance to ensure optimal security and performance.

    These potential drawbacks require careful planning and management to ensure that the use of a reverse proxy brings more benefits than challenges.
